TU 980
Dual band DAB/FM/AM tuner
Sold from 2008 until 2012
Documents & Downloads
Product Specifications
- Power Requirements
- AC 220V – 240V/50Hz
- Power Consumption
- 12W max
- Weight
- 3.4kg
- Dimensions (H x W x D)
- 63mm x 440mm x 334mm
- Frequency Range
- AM... 522kHz – 1620kHz
- Frequency Range
- DAB... Band III... 174MHz – 240MHz
- Frequency Range
- DAB... Band L... 1452MHz – 1492MHz
- Frequency Range
- FM... 87.5MHz – 108MHz
- Input Sensitivity
- DAB... –87dBm
- Signal-to-Noise Ratio
- AM... 0.05%/0.18% (Mono/Stereo)
- Distortion
- AM... 0.15%
- Output Level
- DAB... 1V (–20dBm)
- Signal-to-Noise Ratio
- DAB... 95dB
- Total Harmonic Distortion
- DAB... 0.005%
- Stereo Separation
- DAB... 88dB
- Signal-to-Noise Ratio
- FM... 71dB/65dB (Mono/Stereo)
- Distortion (Mono/Stereo)
- FM... 0.25%/0.4%
The first (more than 50 years ago) Harman Kardon® product was a tuner, and we’ve been improving them ever since. The TU 980 combines the distortion-free, CD-like sound of Digital Audio Broadcasting (DAB) with information-rich RDS FM, and features a bright, legible two-line display. You can control the TU 980 with its own remote, or with the remote from most Harman Kardon amplifiers. Either way, you’ll enjoy the drift-free reception Harman Kardon tuners are famous for.
FAQs & How-Tos
1 results
-
We are sorry, but this is not possible, neither as software upgrade nor as mechanical modification.Was this helpful? Thank you for your feedback!
